AZ733WC - DPDT MINIATURE POWER RELAY
Features:
- High switching capacity
- High dielectric strength, 5000 Vrms
- Isolation spacing greater than 8 mm
- Class B (130°C) insulation standard
- 1.5 mm contact gap (2.0mm contact gap available)
- Recommended replacement: AZ7335W
Engineering Resources
| Contact ratings | Coil Voltage | Contact forms | Coil Power at pickup voltage | ||
|---|---|---|---|---|---|
| 10 A at 30 VDC / 250 VAC | 3 thru 60 VDC | 2 Form C | 0.8 mW | ||
| Typical Life - Electrical | Typical Life - Mechanical | Dielectric Strength(at sea level for 1 min.) | |||
| 100,000 operations at 10 A / 240 VAC Resistive | 500,000 operations | Contact to Coil: 5000 Vrms
Between Open Contacts: 2500 Vrms Contact Set to Contact Set: 3000 Vrms |
|||
| Terminals PC | Terminals Solder / Plug-In | Terminals Bracket Mount | Approvals | Minimum Load | Size in Inches (L x W x H) |
| THT | No | No | UL/CUR/TUV | 5 V, 0.1 A | 1.140 x 0.510 x 1.000 |
